Schneider XVBC5B5 Illuminated Unit
Unidade iluminada Schneider Harmony XVBC5B5 unidade de sinalização iluminada com LED laranja intermitente, alimentação 24 V AC/DC, carcaça de policarbonato e proteção IP66 para sistemas de bancos indicativos industriais.
Schneider XVBC5B5 Illuminated Unit
The Schneider XVBC5B5 illuminated unit is part of the Harmony XVB Universal signalling range, designed for industrial indicator banks and visual signalling systems. This flashing beacon unit features an integral protected LED light source and durable polycarbonate construction, providing reliable signalling performance in automation and machine control environments.
Manufacturer: Schneider
Type: Illuminated Unit
Model: XVBC5B5
MNR: XVBC5B5DB
Order No.: 014478
Serial Number: 3389110144789
| Range Of Product | Harmony XVB Universal |
| Product Or Component Type | Indicator Bank |
| Beacon Or Indicator Bank Unit Type | Illuminated Unit |
| Signalling Type | Flashing |
| Mounting Diameter | 70 mm |
| Component Name | XVBC |
| Material | Polycarbonate |
| Light Source | Integral LED, Orange |
| Bulb Type | Protected LED |
| Rated Supply Voltage (Us) | 24 V AC/DC |
| Rated Insulation Voltage (Ui) | 250 V Conforming To IEC 60947-1 |
| CAD Overall Width | 70 mm |
| CAD Overall Height | 63 mm |
| CAD Overall Depth | 70 mm |
| Standards | EN/IEC 60947-5-1 |
| Protective Treatment | TC |
| Ambient Air Temperature For Storage | -40 / 70 °C |
| Protection Degree | IP66 |
