Sick 6058742 Fork Sensor
Novo
Em estoque6 unidadesPronto para envio
Fork Sensor Sick UFN3 70B417 ultrasonic fork sensor with teach-in adjustment, PNP/NPN outputs, IP65 protection, and fast switching performance for industrial detection and automation systems.
Grande Estoque
Envio Global
Suporte Especializado
Qualidade Garantida
| Part No. | 6058742 |
| Code | 2305 |
| Functional principle | Ultrasonic detection principle |
| Adjustment | Teach-in button (Teach-in, sensitivity, light/dark switching) |
| Switching mode | Light/dark switching |
| Supply voltage | 10 to 30 V DC |
| Current consumption | 40 mA |
| Output current Imax. | 100 Ma |
| Switching frequency | 1.5 kHz |
| Response time | Teach dyn: 3 to 20s, stat 1 to 3s, L/D 20 to 30s |
| Connection type | Male connector M8, 4-pin |
| Switching Output | PNP, NPN |
| Enclosure Protection | IP65 |
| Material | Aluminum |
| Ambient operating temperature | 5 to +55°C |
| Dimensions | 18 mm x 47.5 mm x 92.5 mm |
| Fork width | 3 mm |
| Fork depth | 69 mm |
| Certificate | CE, UKCA, EAC |
| Condition | New |
| Stock Key | JO-004 |
| SKU | 1097856 |
| Weight | 0,16 |
