Sick MZC1-2V2PS-KP0 Cylinder Sensor
| Part No. | 1059735 |
| Class | 2 |
| Cylinder shape | C-slot |
| Cylinder versions with adapter | SMC rail CDQ2, SMC rail ECDQ2 Round cylinder ,Profile and drawbar cylinders |
| Housing length | 23.7 mm |
| Transistor output | PNP |
| Switching frequency | 1,000 Hz |
| Output function | NO |
| Electrical design DC | 3-wire |
| Enclosure rating | IP68 |
| Supply voltage | 10 V DC ... 30 V DC |
| Current consumption | 8 mA, without load |
| Voltage drop | 2.5 V |
| Constant current Ia | 100 mA |
| Protection class | III |
| Reaction sensitivity type. | 2.2 mT |
| Travel distance type. | 4mm |
| Ambient temperature, operation | -30 °C ... +80 °C |
| compatibility According to | EN 60947-5-2 |
| Connection method | Cable with plug M8, 3-pin, suitable for drag chain, 0.3 m |
| Connection method detail Conductor cross-section | 0.09 mm² |
| Cable diameter | 2.2 mm |
| Stock key | CON003 |
| Condition | New |
| SKU | 1100987 |
| Weight | 0,01 |
