Siemens 6ES7 431-1KF10-0AB0 Analog Input Module
375,00$
MÓDULO DE ENTRADA ANALÓGICA Siemens SM 431 módulo de entrada analógica para sistemas SIMATIC S7-400, com 8 canais analógicos, resolução de 14 bits, alimentação 24 V DC e design à prova de explosão EX para interface confiável com sensores industriais.
SIEMENS SM 431 ANALOG INPUT MODULE
The Siemens SM 431 is a high-performance analog input module from the SIMATIC S7-400 family. Designed for industrial automation, it offers reliable connectivity for various sensor types and precise data acquisition. This explosion-proof unit is ideal for demanding environments requiring accurate analog signal processing.
Manufacturer: Siemens
Model: SM 431
Family: SIMATIC S7
Type: Analog Input Module
MRN: 6ES7431-1KF10-0AB0
SN: VPXO502634
Explosion Proof: EX
Used For: SIMATIC S7-400
Input Current:
| Applications | Connection of voltage and current sensors, thermocouples, resistors, and resistance thermometers |
| No. of Analog Inputs | 8 |
| Supply Voltage | 24 V DC |
| From Load Voltage | max. 200 mA |
| From Backplane Bus 5 V DC | max. 600 mA |
| Resolution | 14 bit |
| Power Loss | 3.5 W |
| Isolation | 2120 V DC |
| Operating Temperature | 0 / 60°C |
| Dimensions | 25 x 290 x 210 mm |
