SMC CD85F16-400-B-X2018 ISO Cylinder
Novo
Em estoque1 unidadePronto para envio
ISO Cylinder SMC CD85 series ISO cylinder with a 400 mm stroke and 16 mm bore, featuring a double-acting single-rod design for precise and reliable pneumatic motion control in industrial applications.
Grande Estoque
Envio Global
Suporte Especializado
Qualidade Garantida
| Part No. | 0061133965 / 43 |
| Series | CD85 |
| Fluid | Air |
| Stroke Length | 400 mm |
| Bore Size | 16 mm |
| Piston Rod Diameter | 6 mm |
| Operating Mode | Double Acting, Single Rod |
| Rod Direction | One Side |
| Piston Rod End | Male |
| Shape | Circular |
| Proof Pressure | 1.5 MPa |
| Operating Pressure Max. | 1.0 MPa /10 bar |
| Piston Speed | 50 to 1500 mm/s |
| Piston Rod Thread | M6 x 1 |
| Port Size | 5 mm |
| Material Rod Cover | Aluminum Alloy |
| Material Seals | NBR |
| Material Piston Rod | Stainless Steel |
| Ambient and Fluid Temperature | -20 … 80 °C |
| Stock Key | CON003 |
| Condition | New |
| SKU | 1102378 |
| Weight | 0,29 |
