Turck Q45AD9FPQ Fiber Optic Sensor Amplifier

Manufacturer: TURCK BANNER
Type: Fiber Optic Sensor Amplifier
Model: Q45AD9FPQ
Part No.: 554656

Series: Q45
Wave Length: 660 nm
Operation Mode: Plastic Fiber
Rated Voltage: 5 … 15 V DC
Rated Power Consumption Max.: 60 mA
Output Function: Light Operation, NAMUR
Response Time: 5 ms
Electrical Connection: Female Connector, M12x1, 4-Pin, PVC
Material: Plastic, Thermoplastic
Type of Protection: Ignition EEx ia IIC T6
Protection Class: IP67
Temperature: -40 … 70 °C
Dimensions: 102.5 x 44.5 x 60.5 mm
