VAN Lien LNX 6 Conversion Module
Módulo de Conversão VAN LIEN LNX 6, projetado para converter luminárias padrão em iluminação de rota de emergência com tensão nominal da bateria de 6,0 V e alimentação 220/240 V AC, suportando lâmpadas de até 40W.
VAN LIEN Conversion Module LNX 6
The VAN LIEN Conversion Module LNX 6 is designed for converting standard lighting fixtures into emergency route lighting. It operates with a nominal battery voltage of 6.0V (range: 5-7.2V) and can be used with mains supply of 220/240V AC at 50Hz, with a maximum current of 50mA. This module is ideal for use in emergency lighting systems where it can convert fixtures to ensure illumination in emergency situations. With a compact design, it supports lamp power up to 40W, offering versatile application in a variety of setups.
| Battery Voltage | 6.0V Nominal (Range: 5-7.2V) |
| Mains Supply | 220/240V AC 50Hz, 50mA Max |
| Operating Temperature | 70°C |
| Push Terminal Wire Preparation | 0.5-1.5mm² |
| Cut Terminal Wire | 0.5mm² |
| Lamp Power | 39W / 54W / 40W |
