Balluff BES 516-327-S4-W Inductive Sensor
Б/у
В наличии5 единицыГотово к отправке
Magnetic-Field-Resistant Inductive Sensor
The Balluff BES 516-327-S4-W sensor offers a 10 mm sensing range, cylindrical housing, and robust IP67 protection. It operates with a 10 to 30 V DC voltage range, ideal for flush mounting and various industrial applications.516-327-S4-WBalluffBESbrassHousingInductiveIndustrialIP67M30x1.5Magnetic-Field-ResistantPNPSensingSensortechnology
Новинка
В наличии
Этот продукт также доступен в совершенно новом состоянии
Просмотреть новую версию →
Огромный ассортимент
Глобальная доставка
Экспертная поддержка
Гарантия качества
Balluff BES 516-327-S4-W “ Magnetic-Field-Resistant Inductive Sensor
The Balluff BES 516-327-S4-W magnetic-field-resistant inductive sensor is designed for reliable, high-performance sensing in industrial environments. With a cylindrical housing and flush mounting, it offers robust protection and consistent operation in a range of temperatures.
Manufacturer: Balluff
Type: Magnetic-field-resistant inductive sensor
Model: BES 516-327-S4-W
Order Code: BES02JJ
| Sensing Range | 10 mm |
| Operating Voltage | 10 to 30 V DC |
| Electrical Design | PNP |
| Switching Output | NO |
| Current Rating | 200 mA |
| Housing | Cylindrical |
| Connection | Connector M12x1-Male, 4-pin, A-coded |
| Mounting | Flush |
| Protection Degree | IP67 |
| Housing Material | Brass, PTFE coated |
| Operating Temperature | -25 to 70°C |
| Supplied Items | 2 lock nuts |
| Size | M30x1.5 |
