Beckhoff KL3202 BUS Terminal

В наличии15 единицыГотово к отправке

Bus Terminal

A compact and reliable bus terminal for resistance temperature measurement, supporting multiple RTD sensor types and offering high accuracy, electrical isolation, and seamless integration into Beckhoff K-bus automation systems.

Производитель
BECKHOFF
SKU
1084761
Категория
PLC Modules
Состояние
Б/у
Поделиться
Огромный ассортимент
Глобальная доставка
Экспертная поддержка
Гарантия качества

BECKHOFF KL3202 Bus Terminal

A high-precision bus terminal designed for resistance temperature measurement in industrial automation systems. The KL3202 supports a wide range of RTD sensors and resistance measurements, providing accurate data acquisition and reliable performance in demanding environments. Manufacturer: BECKHOFF

Type: Bus Terminal

Model: KL3202

Serial No.: 04113006

Number Of Inputs2
Power SupplyVia the K-bus
Technology2-/3-wire
Sensor TypesPt100, Pt200, Pt500, Pt1000, Ni100, Ni120, Ni1000, Resistance Measurement (e.g. Potentiometer, 10 Ω / 1.2/5 kΩ)
Measuring Range-200 / +850°C (Pt Sensors); -60 / +250°C (Ni Sensors)
Connection Method2- or 3-wire (Default: 3-wire)
Conversion Time250 ms
Measuring CurrentTyp. 0.5 mA
Electrical Isolation500 V (K-bus / Signal Voltage)
Current Consumption Power Contacts“ (No Power Contacts)
Current Consumption K-busTyp. 60 mA
Bit Width In Process ImageInput: 2 × 16 Bit Data (2 × 8 Bit Control/Status Optional)
ConfigurationNo Address Setting, Configuration via Bus Coupler or Controller
Special FeaturesOpen-Circuit Recognition
Operating Temperature-25 to +60°C
Protection Rating / Installation PositionIP20 / Variable
Approvals / MarkingsCE, CCC, UL, ATEX, IECEx, DNV
Plug-in Wiring LevelFor All KSxxxx Bus Terminals
