Beckhoff KL3202 BUS Terminal

Name: BECKHOFF KL3202 BUS TERMINAL
SKU: 1084761
Availability: LimitedAvailability

Utilisé

En stock15 unitésPrêt à être expédié

Bus Terminal

A compact and reliable bus terminal for resistance temperature measurement, supporting multiple RTD sensor types and offering high accuracy, electrical isolation, and seamless integration into Beckhoff K-bus automation systems.

Fabricant

BECKHOFF

SKU

1084761

Catégorie

PLC Modules

Condition

Utilisé

Automation Beckhoff BUS I/O Industrial Input K-Bus KL3202 Measurement Module PLC Resistance RTD Temperature terminal

Stock massif

Expédition mondiale

Support Expert

Qualité garantie

BECKHOFF KL3202 Bus Terminal

A high-precision bus terminal designed for resistance temperature measurement in industrial automation systems. The KL3202 supports a wide range of RTD sensors and resistance measurements, providing accurate data acquisition and reliable performance in demanding environments. Manufacturer: BECKHOFF

Type: Bus Terminal

Model: KL3202

Serial No.: 04113006

Number Of Inputs	2
Power Supply	Via the K-bus
Technology	2-/3-wire
Sensor Types	Pt100, Pt200, Pt500, Pt1000, Ni100, Ni120, Ni1000, Resistance Measurement (e.g. Potentiometer, 10 Î© / 1.2/5 kÎ©)
Measuring Range	-200 / +850°C (Pt Sensors); -60 / +250°C (Ni Sensors)
Connection Method	2- or 3-wire (Default: 3-wire)
Conversion Time	250 ms
Measuring Current	Typ. 0.5 mA
Electrical Isolation	500 V (K-bus / Signal Voltage)
Current Consumption Power Contacts	“ (No Power Contacts)
Current Consumption K-bus	Typ. 60 mA
Bit Width In Process Image	Input: 2 Ã— 16 Bit Data (2 Ã— 8 Bit Control/Status Optional)
Configuration	No Address Setting, Configuration via Bus Coupler or Controller
Special Features	Open-Circuit Recognition
Operating Temperature	-25 to +60°C
Protection Rating / Installation Position	IP20 / Variable
Approvals / Markings	CE, CCC, UL, ATEX, IECEx, DNV
Plug-in Wiring Level	For All KSxxxx Bus Terminals
