Eurotherm TE 10 P Single Phase True Power Controller

EUROTHERM TE 10 P Single Phase True Power Controller

The EUROTHERM TE 10 P is a high-performance single-phase true power controller designed for precise and efficient power regulation in industrial heating and process control systems. With a rated voltage of 400 V and a robust current handling capacity of 200 A, it is engineered to manage demanding power loads with high accuracy. Operating across a wide supply frequency range of 40 to 70 Hz, this controller is housed in a compact IP20-rated enclosure, ensuring safety and reliability. Its space-efficient design (470 x 133 x 260 mm) makes it easy to integrate into control panels across a variety of industries.

• Manufacturer: EUROTHERM
• Type: Single Phase True Power Controller
• Model: TE 10 P

Technical Specifications:

• Rated Voltage: 400 V
• Rated Current: 200 A
• Supply Frequency: 40 to 70 Hz
• Degree of Protection: IP20
• Operating Temperature: 0 to 45°C
• Dimensions (H x W x D): 470 x 133 x 260 mm
