FAG 22328E1.C3 Spherical Roller Bearing
Yeni
Stokta10 ünitelerSevkiyata hazır
599,99$
Sferik Makaralı Rulman Schaeffler FAG 22328 E1.C3, yüksek yük kapasitesi, C3 boşluğu ve zorlu endüstriyel uygulamalar için 2420 RPM'ye kadar güvenilir performans sunan ağır hizmet tipi sferik makaralı rulmandır.
1402232822328-E1-C32420bearingC3CageCapacityClearanceDutyE1.C3FagHeavyHighIndustrialLoadMetalmmReplacementRollerrpmSchaefflersheetSpherical
Geniş Stok
Küresel Nakliye
Uzman Destek
Kalite Garantili
Schaeffler FAG 22328 E1.C3 Spherical Roller Bearing
The Schaeffler FAG 22328 E1.C3 is a high-performance spherical roller bearing designed for heavy-duty applications requiring high load capacity, durability, and reliable operation under demanding industrial conditions. Its C3 internal clearance and robust steel cage ensure smooth rotation and extended service life.
Manufacturer: Schaeffler FAG
Type: Spherical Roller Bearing
Model: 22328 E1.C3
Replaces: 22328-E1-XL-C3, 22328-E1-C3
| Bore Diameter (d) | 140 millimeters |
| Outer Diameter (D) | 300 millimeters |
| Width | 102 millimeters |
| Dynamic Load Rating | 1,460,000 Newtons |
| Static Load Rating | 1,630,000 Newtons |
| Fatigue Load Limit | 135,000 Newtons |
| Limiting Speed | 2420 RPM |
| Reference Speed | 1660 RPM |
| Radial Internal Clearance | C3 |
| Cage Material | Sheet metal cage |
| Operating Temperature | minus 30 to plus 200 degree Celsius |
