FAG 23232-E1A-K-M Spherical Roller Bearing

Manufacturer: FAG
Type: Spherical Roller Bearing with tapered bore
Model: 23232-E1A-K-M
Replaces: 23232-E1A-XL-K-M, 23232E1AK.M

Dimensions
Bore Diameter d: 160 mm
Outer diameter D: 290 mm
Width B: 104 mm
Basic load ratings, radial:
Dynamic C_r: 1460000 N
Static C_0r: 1910000 N
Fatigue Load Rating: 150000 N
Limiting Speed: 2219 rpm
Reference speed: 1280 rpm
Design: E1A, without central rip
Bore type: K, Tapered, taper 1:12
Cage: M, Solid brass cage
