Festo 132600 Push-IN Fitting
Yeni
Stokta4 ünitelerSevkiyata hazır
Push-In L-Fitting Compact FESTO pneumatic push-in L-fitting with M6 male thread connection, designed for compressed air applications and secure 6 mm tubing installation.
Geniş Stok
Küresel Nakliye
Uzman Destek
Kalite Garantili
| Part No. | 132600 |
| Series | QSM |
| Size | Mini |
| Fluid | Compressed Air |
| Design | Straight Push-Pull Principle |
| Nominal Size | 2.8 mm |
| Operating Pressure | -0.95 ... 6 bar / -0.095 ... 1.4 MPa |
| Tubing Insertion Depth | 11.7 mm |
| Pneumatic Connection, Port 1 | Male Thread M6 |
| Pneumatic Connection, Port 2 | For Tubing Outer Diameter Of 6 mm |
| Material | Brass, Nickel-Plated |
| Ambient Temperature | -10 ... 80 °C |
| Items Per Set | 10 |
| Stock Key | JO-004 |
| Condition | New |
| SKU | 1102210 |
| Weight | 0,06 |
