Lenze MDSKARS056-22 Servo Motor With Gear

LENZE SERVO MOTOR MDSKARS056-22

The LENZE SERVO MOTOR MDSKARS056-22 is designed for high-performance motion control systems. With a high rated torque, excellent speed capabilities, and a robust protection class of IP54, this motor is ideal for precision and heavy-duty applications. The motor is attached to a LENZE GST04-2A VBR 056C22 002 A Gearbox for enhanced performance.

Manufacturer: LENZE

Model: MDSKARS056-22

ID No.: 00455468

Part No.: 0045546810104565

Technical Specifications

• Rated Voltage: 390 VAC
• Rated Torque: 2.0 Nm
• Stall Torque: 2.3 Nm
• Rated Frequency: 140 Hz
• Max Speed: 3950 RPM
• Rated Power: 0.8 kW
• Rated Current: 2.4 A
• Protection Class: IP54
• Insulation Class: F
• Attached with: LENZE GST04-2A VBR 056C22 002 A Gearbox
• Ratio: 24.9
• Max. Torque: 48 Nm
