Oemer 71B/4 Brake Motor

OEMER BRAKE MOTOR 71B/4

The OEMER 71B/4 Brake Motor is designed for high-efficiency performance in industrial applications. With a rated power of 0.37 kW, rated voltage options of 220 delta / 380 star, and a rated speed of 1380 rpm, this motor provides reliable operation. It is also equipped with an ABB FMA100 Electric Brake for enhanced braking performance.

Manufacturer: OEMER

Type: BRAKE MOTOR

Model: 71B/4

Part No: 93M0210

Technical Specifications

• Rated Power [kW]: 0.37
• Rated Voltage [V]: 220 delta / 380 star
• Rated Current [A]: 1.7 / 0.98
• Rated Speed [rpm]: 1380
• Frequency [Hz]: 50
• Power Factor: 0.79
• Protection Class [IP]: 44
• Thermal Class: F

Attached with ABB FMA100 Electric Brake

• Rated Voltage [V]: 220 – 230 delta / 380-400 star
• Rated Current [A]: 0.42 / 0.24
• Rated Torque: 18 Nm
