Pepperl+Fuchs NCB5-18GM60-Z0 Inductive Sensor

Manufacturer: PEPPERL FUCHS

Type: INDUCTIVE SENSOR

Model No.: NCB518GM60Z0

Part Number: 26236S

Successor Model: NCB5-18GM40-Z0

Rated operating distance: 5 mm

Assured operating distance: 0 … 4.05 mm

Operating Voltage: 5 … 60 V DC

Operating Current: 100 mA

Switching frequency: 500 Hz

Switching output: Normally open

Connector type: PUR Cable, 2 m

Protection class: II

Enclosure rating: IP67

Ambient Operating temperature: -25 … 70°C

Diameter, housing length: 18, 60 mm

Housing material: Stainless steel

Sensing face material: PBT

Mounting: Flush-mountable

Condition: New
