Siemens 6XV1850-2GH10 Cabling KIT
Cabling Kit
The SIEMENS 6XV1850-2GH10 Cabling Kit enables secure and efficient connection of terminal devices to IE FC networks. Featuring shielded construction, PE insulation, and PVC sheath, it ensures reliable data transmission in industrial environments.SIEMENS 6XV1850-2GH10 Cabling Kit
The SIEMENS 6XV1850-2GH10 Cabling Kit is a high-quality industrial connection solution designed for easy and reliable integration of terminal devices into the IE FC cabling system. Engineered for robust data transmission, this cabling kit features shielded construction, high insulation resistance, and excellent electromagnetic compatibility, making it ideal for industrial communication and automation environments.
Manufacturer: SIEMENS
Type: Cabling Kit
MRN: 6XV1850-2GH10
Serial No.: 4019169401623
| Suitability for Use | Easy connection of terminal devices to the IE FC cabling system |
| Cable Designation | LI 02YSCY 2x2x0.15/0.98 PIMF ICCS GN |
| Wire Length | 1 m |
| Number of Electrical Connections | 2 |
| Loop Resistance per Length (Max) | 300 mΩ/m |
| Insulation Resistance Coefficient | 150 GΩ·m |
| Operating Voltage (RMS) | 80 V |
| Number of Electrical Cores | 4 |
| Shield Design | Overlapped aluminum-clad foil with braided screen of tin-plated copper wires |
| Core Diameter (AWG26 Insulated Conductor) | 0.48 mm |
| Outer Diameter of Inner Conductor | 0.48 mm |
| Outer Diameter of Wire Insulation | 0.98 mm |
| Cable Sheath Width | 5.8 mm |
| Wire Insulation Material | Polyethylene (PE) |
| Cable Sheath Material | PVC |
| Ambient Temperature During Operation | ˆ’40 / +70 °C |
| Protection Class | IP20 |
