Sigmatek AI088 Analog Input Module

Manufacture: Sigmatek
Type: Analog Input Module
Model: AI 088
Art. No.: 20-009-088

Thermal Element Input Specifications
Number of channels: 8
Converter resolution: 16-bit
Conversion time per channel: 1 ms
Over voltage protection: 265 V AC
Sensor types: J,K,T,E,N,S,R,B,L,U
Measurement range: 0 … +1820 °C
Analog Inputs:
Type: KTY temperature sensor
Number: 2
Resolution: 16 bits
Sensor types: KTY10-62 or KTY11-62
Measurement range: -20 … +80 °C
Protection degree: IP20
Ambient temperature: 0 … 60°C
Dimensions: 12.5 x 104.2 x 72 mm
