Urmet 1033/190 Active Synchronized IR Barriers
Manufacturer: Urmet
Type: Active Synchronized IR Barriers
Model: 1033/190
Power Supply: 12/24 Vcc/Vca
Absorption: 60 mA
Nominal Flow: 150 m max.
Reach Outside: 50 m max.
Signal Transmitted: Modulated Infrared
Wavelength: 950 nm
Modulation: Impulsive
Pause Duration Time: 7 ms
Impulse Duration Time: 20 ms
Pulse Withdrawal Time: 2 ms
Operation: With or Without Synchronism
Operating Temperature: -20…70 °C
Intervention Time: 30 ÷ 300 ms
Relay Excitation Time: 1 s Minimum
Contacts Relay: NC
Relay Contact Range: 1 A @24 Vcc
Horizontal Angle Mirrors 180 °C
Dimension: 127 x 60 x 55 mm
Weight: 0.27 kg
Attachment: DISIORE L9071A0 BOARD
Manufacturer: Urmet / Disiore
Type: Board
Model: L9071A0
| Teknik Özellikler | Değer |
|---|---|
| Condition | New |
| Shelf No. | 220701 |
