ABB S201 C6 Miniature Circuit Breaker
جديد
متوفر2 وحداتجاهز للشحن
Miniature Circuit Breaker The ABB S201-C6 is a single-pole, 6 A miniature circuit breaker with a Type C trip curve and 6 kA short-circuit capacity, designed for reliable electrical circuit protection.
مخزون ضخم
شحن عالمي
دعم من خبراء
جودة مضمونة
| Product ID | 2CDS251001R0064 |
| Function | Protection and Control of the Circuits Against Overloads and Short-Circuits; Protection for Resistive and Inductive Loads with Low Inrush Current. |
| Rated Voltage | 480Y / 277 V AC / 60 V DC |
| Rated Current | 6 A |
| Rated Insulation Voltage | 440 V AC |
| Frequency | 50 … 60 Hz |
| Rated Impulse Voltage | 4 kV |
| Power Loss | 2 W |
| Trip Curve | Type C |
| Number of Poles | 1-Pole |
| Rated Short-Circuit Capacity | 6 kA |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu) (400V) | 10 kA |
| Rated Service Short-Circuit Breaking Capacity (Ics) | (133 V AC) 15 kA / (230 V AC) 7.5 kA |
| Protection Class | IP40 |
| Temperature | -25 ... 55 °C |
| Dimensions | 17.5 x 88 x 69 mm |
| Stock Key | CON003 |
| Condition | New |
| SKU | 1104071 |
| Weight | 0,13 |
