Aplisens SGE-25 Hydrostatic Level Probe

Manufacturer: APLISENS
Type: Hydrostatic Level Probe
Model: SGE-25
Ser. No.: 12162299

Application: hydrostatic level probe is applicable
to measure liquid levels in tanks, deep wells
or piezometers
Measuring Range: 0 … 5 m H₂O
Over Pressure Limit: 25 m H₂O
Operating Voltage: 8 … 36 V DC
Output Signal: 4 … 20 mA
Connector Type: Cable,3-wire
Diameter, Housing Length: 25,156 mm
Housing Material: SS316L
Material of Diaphragm: Hastelloy C276
Leve Probe connection: Probe with Pt100 sensor
Thermal Compensation Range: 0 … 40°C
Medium Operating Temperature: -30 … 40°C
Enclosure Rating: IP68
