Autonics TM4-N2SB PID Temperature Controller
جديد
متاح عند الطلب
PID Temperature Controller The Autonics TM4-N2SB is a modular 4-channel PID temperature controller with thermocouple and RTD inputs, 100 ms sampling, and RS485 Modbus RTU communication.
مخزون ضخم
شحن عالمي
دعم من خبراء
جودة مضمونة
| Series | TM4 |
| Input Channels No. | 4 |
| Sampling Cycle | 100 ms (4-Channel Synchronous Sampling) |
| Input Types | Thermocouples (B, C, E, G, J, K, L, N, PLII, R, S, T, U) and RTDs (DPt100O, DPt50O, JPt100O, JPt50O, Cu50O, Cu100O, Ni120O) |
| Power Voltage | 24 V DC |
| Power Consumption Max. | 5 W |
| Control Output | 22 V DC, 3V, 30 mA |
| Communication | RS485 (Modbus RTU) |
| Protection Class | IP50 |
| Temperature | -10 … 50 °C |
| Dimensions | 100 x 30 x 103.5 mm |
| Stock Key | CH001 |
| Condition | New |
| SKU | 1103990 |
| Weight | 0,22 |
