Beckhoff AM8053-1KH0-0000 Servomotor
جديد
متوفر4 وحداتجاهز للشحن
1 555,55$
Servomotor The BECKHOFF AM8053-1KH0-0000 servomotor delivers high precision, 3.5 kW power, and 11.4 Nm torque, designed for dynamic industrial drive applications with advanced encoder options.
مخزون ضخم
شحن عالمي
دعم من خبراء
جودة مضمونة
| Part No. | 206492 |
| BTN stands | aa403ix8 |
| Rated Voltage | 400 V |
| Rated Speed | 4000 rpm |
| Stall Torque | 11.4 Nm |
| Rated Power | 3.5 KW |
| Stall Current | 8.8 A |
| standard | EN 60034-1 |
| Thermal class | F |
| suitable for | drive solutions with highest demands on dynamics and performance in the 100…480 V AC voltage range |
| Torque constant | 1.29 Nm/A |
| Rotor moment of inertia | 5.93 kgcm² |
| Motor feedback | resolver, single-turn absolute encoder |
| Cooling | convection |
| Connection technology | M23 speedtec® plug |
| Ambient temperature (operation) | 5…40°C |
| Protection rating | IP54 |
| Design form | flange-mounted according to IM B5, IM V1, IM V3 |
| Material | aluminum |
| Coating/surface | acrylic powder-coated, dark gray, similar to RAL7016 |
| Shaft diameter | 24 mm |
| Stock key | JO-004 |
| Condition | New |
| SKU | 1096837 |
| Weight | 8 |
