Beckhoff AM8112-1F11-0000 Servomotor
جديد
متوفر26 وحداتجاهز للشحن
444,44$
Servomotor The BECKHOFF AM8112-1F11-0000 is a compact 48 VDC servomotor delivering 4500 rpm speed, 0.38 Nm torque, and precise motion control with advanced encoder options and reliable industrial design.
48VDCAM8112-1F11-0000AutomationBeckhoffCompactEncoderFlangeIndustrialIP54motormountedPrecisionServoServomotor
مخزون ضخم
شحن عالمي
دعم من خبراء
جودة مضمونة
| Part No. | 127897 |
| BTN stands | aa401e1e |
| Rated Voltage | 48 vdc |
| Rated Speed | 4500 rpm |
| Stall Torque | 0.38 Nm |
| Rated Power | 0.17 KW |
| Stall Current | 4.7 A |
| standard | EN 60034-1 |
| Brake Voltage, power | 24Vdc / 10W |
| Thermal class | B |
| Motor feedback | resolver, single-turn absolute encoder |
| Cooling | convection |
| Connection technology | itec® plug |
| Ambient temperature (operation) | 5…40°C |
| Protection rating | IP54 |
| Design form | flange-mounted according to IM B5, IM V1, IM V3 |
| Material | aluminum |
| Coating/surface | acrylic powder-coated, dark gray, similar to RAL7016 |
| Shaft diameter | 8 mm |
| Stock key | JO-004 |
| Condition | New |
| SKU | 1096828 |
| Weight | 1 |
