Hydraulics & Pneumatics Pneumatic Valves

Burkert 2002 B 32,0 Ptfe VA Angle Seat Valve

Name: BURKERT 2002 B 32,0 PTFE VA ANGLE SEAT VALVE
SKU: 1081978
Availability: LimitedAvailability

burkert-2002-B-32.0-PTFE-VA-angle-seat-valve-(new)-(carton)

burkert-2002-B-32.0-PTFE-VA-angle-seat-valve-(new)-(carton)-1

burkert-2002-B-32.0-PTFE-VA-angle-seat-valve-(new)-(carton)-3

burkert-2002-B-32.0-PTFE-VA-angle-seat-valve-(new)-(carton)-2

جديد

متوفر1 وحدةجاهز للشحن

Angle Seat Valve

Burkert 2002B32,0PTFEVA pneumatically actuated angle seat valve with DN 32 mm, PN 25 bar, and max operating pressure of 16 bar. Designed for air and process control up to 135 °C.

الشركة المصنّعة

BURKERT

SKU

1081978

الفئة

Pneumatic Valves

الحالة

جديد

00141029 0PTFEVA 2002B32 Air Angle Automation Burkert Control DN32 High Industrial PN25 Pneumatic Pressure Process Seat Valve W37LN

مخزون ضخم

شحن عالمي

دعم من خبراء

جودة مضمونة

Burkert Angle Seat Valve 2002B32,0PTFEVA

The Burkert 2002B32,0PTFEVA Angle Seat Valve is a pneumatically actuated valve designed for reliable control of fluids and gases under demanding industrial conditions. With high pressure capacity, durable sealing, and excellent temperature resistance, it ensures long-lasting performance in automation and process systems.

Manufacturer: Burkert

Type: Angle Seat Valve

Model: 2002B32,0PTFEVA

ID. No.: 00141029

Code: W37LN

Type of Actuation	Pneumatically
Max Pressure	16 bar
Pilot Operating Pressure	2 to 10 bar
Fluid	Air
Nominal Diameter DN	32 mm
Nominal Pressure PN	25 bar
Connection	G1/4, G1 1/4
Ambient Temperature	max. 135 °C
