Asco G551A001MS Single Solenoid Valve With Coil (43004869)
مستعمل
متوفر1 وحدةجاهز للشحن
150,00$
Solenoid Valve With Coil
The ASCO JOUCOMATIC G551A001 MS valve with 43004869 coil provides reliable 5 by 2 or 3 by 2 air control, 10 bar pressure rating, and durable aluminum body with 24 VDC electrical actuation.102243430048695551AluminumAscobarbycoilComponentG551A001IndustrialJoucomaticmsPneumaticSeriessolenoidValveVDCWay
مخزون ضخم
شحن عالمي
دعم من خبراء
جودة مضمونة
ASCO JOUCOMATIC G551A001 MS Solenoid Valve With 43004869 Coil
The ASCO JOUCOMATIC G551A001 MS Solenoid Valve is a robust and versatile pneumatic valve designed for efficient air control in automation systems. Built from anodized aluminum, it offers reliable switching performance with both 5 by 2 and 3 by 2 normally closed functions. This valve is equipped with the ASCO 43004869 Solenoid Coil for precise electrical actuation and long service life.
Manufacturer: ASCO JOUCOMATIC
Type: Solenoid Valve
Model: G551A001 MS
Series: 551
Technical Information (Valve)
- Maximum Operating Pressure: 10 bar
- Fluid: Air
- Function: 5 by 2 or 3 by 2 normally closed way
- Body and End Cover: Aluminum, black anodized
- Attached Coil Model: 400904-542
- Attachment: ASCO 43004869 Solenoid Coil
Technical Information (Coil)
- Manufacturer: ASCO JOUCOMATIC
- Type: Solenoid Coil
- Model: 43004869
- Part Number: 400904-042
- Reference Number: 268-41
- Voltage: 24 VDC
- Power: 2.5 W
- Medium: Compressed air, filtered (lubricated or non-lubricated)
- Port Size: G1/4 and G1/8
