Schunk PSH-32-1 Long-Stroke Gripper

Manufacturer: SCHUNK
Type: Long-stroke gripper
Model: PSH-32-1
Part No.: 302132

Stroke per jaw: 35 mm
Closing force: 750 N
Opening force: 750 N
Closing force (with finger lengths of 0 mm): 810 N
Opening force (with finger lengths of 0 mm): 810 N
Recommended workpiece weight: 3.75 kg
Fluid consumption double stroke: 101 cm³
Min. operating pressure: 3 bar
Max. operating pressure: 8 bar
Nominal operating pressure: 6 bar
Closing time: 0.2 s
Opening time: 0.2 s
Max. permissible finger length: 170 mm
ambient temperature [°C]: 5 … 90
Repeat accuracy: 0.1 mm
Length X: 171 mm
Width Y: 76 mm
Height Z: 63 mm
