DI-Soric DCC 08 M 02 PSK-TSL Inductive Proximity Sensor
جديد
متوفر1 وحدةجاهز للشحن
Inductive Proximity Sensor di-soric inductive proximity sensor with 2 mm sensing distance, PNP normally open outputand IP67 protection for industrial automation applications.
مخزون ضخم
شحن عالمي
دعم من خبراء
جودة مضمونة
| Article Number | 206437 |
| Hennecke Item Number | 331000-0017 |
| Service voltage | 10 … 30 V DC |
| Internal power consumption | 10 mA |
| Insulation voltage endurance | 500 V |
| Installation type | Flush |
| Thread | M8 x 1 |
| Housing length | 45 mm |
| Housing material | Stainless steel |
| Tightening torque | 4 Nm |
| Protection class | III, operation on protective low voltage |
| Operating principle | inductive |
| Evaluation | digital |
| Design | Thread |
| Switching output | pnp, 200 mA, NO |
| Voltage drop (max.) | 2.4 V |
| Switching distance (SN) | 2 mm |
| Standardized measuring plate | 8 x 8 x 1 mm |
| Switching frequency | 2000 Hz |
| Ambient temperature during operation | -25 … +70 °C |
| Protection type | IP 67 |
| Connection | Connector, M8, 3-pin, A-coded |
| Stock key | CON003 |
| Condition | New |
| SKU | 1101024 |
| Weight | 0,02 |
