Festo 192027 Pressure Sensor

Manufacturer: FESTO
Type: Pressure sensor
Model: SDE1-D10-G2-R18-C-P2-M8
Part No.: 192027

Pressure measuring range, initial value: 0 bar
Pressure measuring range, final value: 10 bar
Operating medium: Compressed air
Ambient temperature: 0 … 50 °C
Accuracy, FS: 2 %FS
Switch output: PNP
Switching function: Freely programmable
Switching element function: Switchable
Switching point reproducibility: 0.3 %
Max. output current: 150 mA
Analogue output: 0 – 10 V
Short circuit strength: Pulsing
Operating voltage range: DC 15 … 30 V
Electrical connection: Plug Round design to  EN 60947-5-2 M8x1 4-pin
 Port size: 4 mm
