INA KRV30-PP-A Stud Type Track Roller
رولل مسار من نوع المسمار رولر مسار من نوع المسمار Schaeffler INA KRV30-PP-A يتميز بقطر خارجي 30 مم وقطر مسمار الرولر 12 مم ونظام ثلاثي المراحل للختم، مما يوفر قدرة تحميل شعاعية عالية ومتانة للأنظمة الصناعية.
Schaeffler INA KRV30-PP-A Stud Type Track Roller
The Schaeffler INA KRV30-PP-A Stud Type Track Roller is designed for demanding applications where high-load capacity and durability are essential. With its high-quality construction, this track roller offers reliable performance for a variety of industrial machinery applications.
Manufacturer: Schaeffler INA
Type: STUD TYPE TRACK ROLLER
Model: KRV30-PP-A
Basic Load Ratings, Radial:
This stud-type track roller is designed to offer high radial load capacity, precise performance, and reliable sealing, making it an excellent choice for heavy-duty industrial applications.
| Outside Diameter (D) | 30 mm |
| Fit Diameter of Roller Stud (d1) | 12 mm |
| Width of the Roller Stud (B) | 40 mm |
| Roller Width | 15.2 mm |
| Thread (G) | M12X1.5 |
| Thread Length | 13 mm |
| Dynamic Cr w | 9500 N |
| Static C0r w | 15100 N |
| Fatigue Load Limit Cur w | 2080 N |
| Speed on Permanent Grease Lubrication | 2100 1/min |
| Sealing | PP, Three-stage sealing by plastic axial plain washer on both sides |
