INA KWVE25-B-ESC-RROC-V1-G3 Recirculating Ball Bearing ‎Carriage

Manufacturer: Schaeffler INA

Type: Recirculating ball bearing carriage

Model: KWVE25-B-ESC-RROC-V1-G3

Size: 25 mm

Height system: 33 mm

Width carriage: 48 mm

Overall length carriage: 58.2 mm

Basic Load Ratings, Linear:

Dynamic C_r: 12.5 kN

Static C_0r: 22 kN

Carriage design: ESC; Expanded design, short, narrow carriage

Preload: V1; preload class 1

Accuracy class: G3

Weight: 0.32 kg
