Orsta WS4 Valve Coil
مستعمل
متوفر3 وحداتجاهز للشحن
Valve Coil
The Orsta WS 4 Valve Coil is built for continuous duty operation with 220 V AC, IP54 protection, and reliable actuation performance for hydraulic and pneumatic valves.
مخزون ضخم
شحن عالمي
دعم من خبراء
جودة مضمونة
Orsta WS 4 Valve Coil
The Orsta WS 4 is a high-performance valve coil designed for continuous duty in demanding industrial applications. With robust construction and a reliable IP54 protection class, this coil ensures durability and stable operation under varied conditions. It is ideal for precise actuation in hydraulic and pneumatic valve systems.
Manufacturer: Orsta
Type: Valve Coil
Model: WS 4
| Rated Voltage (Un) | 220 V AC |
| Current (I) | 0.4 A |
| Magnet Current (IA) | 3.2 A |
| Holding Force (H. Kraft) | 12 kp (approx. 118 N) |
| Magnetic Force (Mag. Kraft) | 5 kp (approx. 49 N) |
| Stroke (Hub) | 0.8 cm (8 mm) |
| Duty Cycle (ED) | 100 % (continuous duty) |
| Frequency | 50 Hz |
| Switching Rate | 120 switching cycles/hour |
| Mounting | Flange base with central bore |
| Weight Code (from plate) | 5 MNT 00/05 |
| Protection Class | IP54 |
