Automation & Control Power Supplies

Puls CPS20.241-C1 Single Phase Input

Name: PULS CPS20.241-C1 SINGLE PHASE INPUT
SKU: 1093779
Availability: LimitedAvailability

puls-CPS20-241-C1-single-phase-input-(new)-(carton)

puls-CPS20-241-C1-single-phase-input-(new)-(carton)-1

puls-CPS20-241-C1-single-phase-input-(new)-(carton)-2

puls-CPS20-241-C1-single-phase-input-(new)-(carton)-3

puls-CPS20-241-C1-single-phase-input-(new)-(carton)-4

puls-CPS20-241-C1-single-phase-input-(new)-(carton)-5

puls-CPS20-241-C1-single-phase-input-(new)-(carton)-6

جديد

متوفر1 وحدةجاهز للشحن

Single Phase Power Supply PULS C Series 480 W industrial power supply with 24 V DC output, adjustable 24–28 V DC range, and high efficiency for industrial automation and control applications.

الشركة المصنّعة

PULS

SKU

1093779

الفئة

Power Supplies

الحالة

جديد

مخزون ضخم

شحن عالمي

دعم من خبراء

جودة مضمونة

Series	C
S/N	20 257 485
Code	125501000084
Output voltage	24 V DC (Adjustable range: 24–28V DC)
Input Voltage	(AC 120–240V (-15% / +10%), 5.3–2.7A, 50–60Hz),(AC 100V (-15% / +10%), 6.4A, 50–60Hz)
Output Power	480W
Adjustment range	24-28V DC
Output current	For AC 120-240V mains (20.0-17.1A at +60°C ambient, 15.0-12.8A at +70°C ambient), For AC 100V mains (17.0-14.5A at +60°C ambient), (12.8-10.9A at +70°C ambient)
Efficiency	92.7 / 94.0% at 120 / 230Vac
Losses	37.8 / 30.6W at 120 / 230Vac
Temperature range	-25°C to +70°C
Dimensions	65x124x127mm
Condition	New
Stock key	CON003
SKU	1093779
Weight	1,11
