Schunk MPG32 Parallel Gripper

Manufacturer: SCHUNK
Type: Parallel gripper
Model: MPG 32
Part No.: 340011

Stroke per jaw: 4.0
Closing force: 65.0 N
Opening force: 55.0 N
Closing force (with finger lengths of 0 mm): 68.0 N
Opening force (with finger lengths of 0 mm): 58.0 N
Recommended workpiece weight: 0.33
Cylinder volume per double stroke: 1.6 cm³
Min. operating pressure: 2.0 bar
Max. operating pressure: 8.0 bar
Closing time: 0.025 S
Opening time: 0.025 S
Max. permissible finger length: 32.0 mm
Max. permissible weight per finger: 0.04 kg
IP protection class: 30
Min. ambient temperature: 5.0 °C
Max. ambient temperature: 90.0 °C
Repeat accuracy: 0.02 mm
Moment Mx max.: 1.5 Nm
Port size: 5 mm
