Palazzoli 477302 Straight Plug Connector
Gebraucht
Auf Lager1 EinheitVersandbereit
Straight Plug Connector
The Palazzoli 477302 straight plug connector offers a reliable 16 A CEE connection with IP44 protection and robust technopolymer construction for industrial electrical applications.
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie
Palazzoli 477302 Straight Plug Connector
The Palazzoli 477302 Straight Plug Connector is a durable and reliable industrial power connector designed for secure electrical connections in demanding environments. As part of the CEE series, it ensures safe operation, impact resistance, and stable performance across a wide temperature range.
Manufacturer: Palazzoli
Type: Straight Plug Connector
Model: 477302
| Series | CEE |
| Rated Operating Voltage | 200 / 250 V AC |
| Rated Current | 16 A |
| Frequency | 50 / 60 Hz |
| Clock Position | 6 h |
| Poles No. | 2P+E |
| Material | Technopolymer Recyclable Palazzoli |
| Protection Class | IP44 |
| Ambient Temperature | -25 / 50 °C |
| Length | 134 mm |
