SKF 7312 Becbj Angular Contact Ball Bearing
Neu
Auf Lager6 EinheitenVersandbereit
Kugellager mit schrägem Anlauf SKF 7312BECBJ, einzeln, mit 60 mm Bohrung, 40° Kontaktwinkel, dynamischer Tragzahl von 104 kN und P6 Toleranzklasse für Hochgeschwindigkeits-Industriedrehungen.
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie
SKF 7312BECBJ Angular Contact Ball Bearing
The SKF 7312BECBJ is a single row angular contact ball bearing designed to accommodate combined radial and axial loads at high speeds. With a 40° contact angle and precision manufacturing, it delivers reliable performance in demanding industrial applications.
Manufacturer: SKF
Type: Single Row Angular Contact Ball Bearing
Model: 7312BECBJ
Load Ratings & Performance
Design & Accuracy
| Bore Diameter (d) | 60 mm |
| Outer Diameter (D) | 130 mm |
| Width (B) | 31 mm |
| Contact Angle | 40 Degrees |
| Basic Dynamic Load Rating (Cr) | 104 kN |
| Basic Static Load Rating (C0r) | 76.5 kN |
| Fatigue Load Limit | 3.2 kN |
| Limiting Speed | 6700 rpm |
| Reference Speed | 6300 rpm |
| Cage | Steel Sheet Metal |
| Matched Arrangement | No |
| Universal Matching Bearing | Yes |
| Axial Internal Clearance | Not Applicable |
| Tolerance Class | Class 6 (P6) |
