Danfoss MP55A 060B0183 Differential Pressure Switch With Timer
Usado
En stock1 unidadListo para enviar
Differential Pressure Switch The DANFOSS MP55A differential pressure switch is designed for monitoring oil differential pressure in industrial systems. It features an adjustable pressure range, SPDT contacts, and a robust aluminium die-cast housing for dependable operation.
Inventario Masivo
Envío global
Soporte experto
Calidad Garantizada
| Part No. | 060B0183 |
| Series | MP |
| Fluid | Oil |
| Differential Pressure Measuring Range | 0.3 … 4.5 bar |
| Switch Differential Pressure | 0.2 bar |
| Operating Pressure Max. | 17 bar / 245 psig |
| Switching Function | SPDT |
| Contact Rating | 250 V AC/DC / 2 / 0.2 A |
| Frequency | 50 … 60 Hz |
| Pressure Connection | G1/4 |
| Material | Aluminium Die Casting |
| Protection Class | IP20 |
| Fluid Temperature Range | -40 … 60 °C |
| Stock Key | CON003 |
| Condition | Used |
| SKU | 1102918 |
| Weight | 0,69 |
