FAG KM 18 Lock NUT
Nuevo
En stock2 unidadesListo para enviar
Tuerca de seguridad FAG KM18 de precisión con rosca M90 × 2, alta capacidad de carga axial y dimensiones precisas para aplicaciones de montaje seguro de rodamientos.
Inventario Masivo
Envío global
Soporte experto
Calidad Garantizada
FAG KM18 Lock Nut
The FAG KM18 lock nut is a precision-engineered bearing accessory designed to securely locate bearings on shafts. It ensures reliable axial positioning and long-term operational stability in demanding industrial applications.
Manufacturer: FAG
Type: Lock Nut
Model: KM18
| Outside Diameter | 120 mm |
| Width | 16 mm |
| Chamfer Diameter d1 | 108 mm |
| Width Retaining Slot b | 10 mm |
| Groove Base Distance | 112 mm |
| Thread Designation | M90 × 2 |
| Axial Load Capacity (Static) | 240,000 N |
| Chamfer Angle | 30° |
