Hohner 10-12121-1000 Incremental Encoder
Usado
En stock1 unidadListo para enviar
129,99$
Industrial incremental encoder featuring 1000 pulses per revolution, a solid 10 mm shaft, IP67 protection, and a maximum mechanical speed of 6000 rpm for accurate motion control and position feedback applications.
Inventario Masivo
Envío global
Soporte experto
Calidad Garantizada
| Part No. | 10-12121-1000 |
| Part No. | 491643 |
| Series | 10 |
| Shaft Type | Solid Shaft |
| Power Supply Voltage | 11 to 30 V DC |
| Shaft Diameter | 10 mm |
| Pulses per Revolution | 1000 ppr |
| Protection Degree | IP67 |
| Maximum number of revolutions permitted mechanically | 6000 rpm |
| Connection | Connector,plug |
| Flange | 58 mm |
| Starting Torque Max. | 0.02 N.m |
| Cover Material | Zamac |
| Housing Material | Aluminum |
| Shaft Materials | Stainless Steel |
| Operating Temperature | -20 to +80 °C |
| Condition | Used |
| SKU | 1099374 |
| Weight | 0,34 |
