Hohner AWI58S-102R051 Incremental Encoder

Name: HOHNER AWI58S-102R051 INCREMENTAL ENCODER
Brand: HOHNER
SKU: 966001
Price: 50.00 USD
Availability: InStock

hohner-awi58s-102r051-incremental-encoder3_675x450

hohner-awi58s-102r051-incremental-encoder4_675x450

hohner-awi58s-102r051-incremental-encoder5_675x450

Usado

En stock1 unidadListo para enviar

50,00$

ENCÓDERE INCREMENTAL HOHNER AWI58S-102R051 proporciona retroalimentación de alta precisión con eje sólido de acero inoxidable de 10 mm, frecuencia de 100 kHz y salida Push-Pull (HTL), diseñado para condiciones industriales duras con protección IP65.

Fabricante

HOHNER

SKU

966001

Categoría

Rotary Encoders

Condición

Usado

10 100 AWI58S-102R051 Connector Encoder Feedback High-Speed Hohner HTL Incremental Industrial IP65 kHz mm Output Protected Push-Pull Sensor shaft Valve

Inventario Masivo

Envío global

Soporte experto

Calidad Garantizada

HOHNER AWI58S-102R051 INCREMENTAL ENCODER

The HOHNER AWI58S-102R051 Incremental Encoder offers high-resolution signal feedback for demanding automation and industrial positioning systems. With a rugged stainless steel shaft and IP65 protection, it is ideal for high-speed and harsh environments.

Manufacturer: HOHNER

Type: Incremental Encoder

Model: AWI58S-102R051

IDN: 381

Shaft Diameter	10 mm
Shaft Design	Stainless Steel Solid
Voltage Supply	10 / 30 VDC
Output Current	30 mA
Output Circuit	Push-Pull (HTL)
Signal Output	A, B
Max Speed	6.000 U/min
Max. Pulse Frequency	100 kHz
Output Connections	Valve Connector, Radial
Protection Class	IP 65
Temperature Range	-30 / 70 °C
