INA AM 20 Precision Locknut
Nuevo
En stock10 unidadesListo para enviar
66,66$
Tuerca de precisión INA AM 20 con rosca M20X1 y diámetro exterior de 38 mm. Soporta una carga axial de hasta 145,000 N y ofrece un montaje seguro con diversas especificaciones de torque.
Inventario Masivo
Envío global
Soporte experto
Calidad Garantizada
INA AM 20 Precision Locknut
The INA AM 20 Precision Locknut is designed for secure mounting and high-performance applications. With robust axial load capacity and precise dimensions, it ensures reliable locking and easy installation in machinery setups.
Manufacturer: INA
Type: Precision Locknut
Model: AM 20
| Thread d | M20X1 |
| Pitch Circle Diameter 1 (Holes) d1 | 31 mm |
| Outside Diameter D | 38 mm |
| Height h | 18 mm |
| Mounting Torque Set Screw | 5 Nm |
| Breaking Load, Axial FaB | 145,000 N |
| Breakaway ML | 45 Nm |
| Mounting Torque Reference MAL | 18 Nm |
