Bearings Housing Units Plummer Block Housing Units

Nachi Ucech 210 Hanger Unit

Name: NACHI UCECH 210 HANGER UNIT
SKU: 1089933
Availability: LimitedAvailability

nachi-UCECH-210-hanger-unit-(new)-(carton)

nachi-UCECH-210-hanger-unit-(new)-(carton)-1

nachi-UCECH-210-hanger-unit-(new)-(carton)-2

nachi-UCECH-210-hanger-unit-(new)-(carton)-3

nachi-UCECH-210-hanger-unit-(new)-(carton)-4

Nuevo

En stock8 unidadesListo para enviar

Unidad de soporte Nachi unidad de soporte UCECH210 con rodamiento UC210 y carcasa de hierro fundido, con bloqueo por tornillo de fijación y alta capacidad de carga para aplicaciones industriales.

Fabricante

NACHI

SKU

1089933

Categoría

Plummer Block Housing Units

Condición

Nuevo

bearing bore Cast Cylindrical Hanger Housing Industrial Iron mounted Nachi screw Set UC210 UCECH210 Unit

Inventario Masivo

Envío global

Soporte experto

Calidad Garantizada

Nachi UCECH210 Hanger Unit

The Nachi UCECH210 hanger unit is designed to provide stable bearing support and reliable load handling in industrial machinery. It combines a UC210 bearing with an ECH210 cast iron housing, offering durability, accurate shaft alignment, and secure mounting.

Manufacturer: Nachi

Type: Hanger Unit

Model: UCECH210

Bearing Number: UC210

Housing Number: ECH210

Bore Diameter (d)	50 mm
Overall Length (L)	114 mm
Overall Height (H1)	83 mm
Width of Inner Ring (B)	51.6 mm
Height (H)	140 mm
Housing Width (A)	48 mm
Distance Front Side / Bearing Center (S)	19 mm
Basic Load Dynamic Rating	35,500 N
Basic Load Static Rating	23,200 N
Locking Device	Set Screw
Design	Cylindrical Bore
Housing Material	Cast Iron
