Palazzoli 579750 Topter Wall-Mounted BOX

Palazzoli Topter Wall-Mounted Box for 1 Socket (Model: 579750)

The **Palazzoli Topter Wall-Mounted Box for 1 Socket** (Model: 579750) is designed for durable and reliable electrical installations in harsh environments. With high protection ratings of IP66/IP67 and shock resistance IK08, this box ensures long-term performance even in extreme temperatures and outdoor conditions.

Manufacturer: PALAZZOLI

Type: Topter Wall-Mounted Box for 1 Socket

Model: 579750

MRN: A3 079 / A3 080

Technical Data:

• Hole Type: M25
• Min. Ambient Temperature: -25°C
• Max. Ambient Temperature: +50°C
• Rated Insulation Voltage: 1000 V
• Shock Resistance: IK08 according to IEC/EN 62262
• Dimensions: 84 x 100 x 65 mm
• Protection Class: IP66/IP67
• Attached with: PALAZZOLI 579860 Watertight Cap

PALAZZOLI 579860 Watertight Cap

The **PALAZZOLI 579860 Watertight Cap** is designed to ensure secure closure for the Topter Box, providing additional protection against water and dust ingress. It is engineered to fit perfectly with the wall-mounted box for an enhanced seal and durability.

Technical Data:

• Flange Dimensions: 65 x 83 mm
