Parker BBIZE-1-1/2-N-B10 Thermostatic Expansion Valve
Nuevo
En stock1 unidadListo para enviar
Thermostatic Expansion Valve PARKER / SPORLAN thermostatic expansion valve for R-22 and R-410A refrigerants, designed for reliable flow control in air conditioning and outdoor chiller systems.
Inventario Masivo
Envío global
Soporte experto
Calidad Garantizada
| Alternative Model | REAA402293 |
| Part No. | 169430 |
| Range | SPORLAN |
| Application | Air Conditioning, Outdoor Chiller |
| Refrigerant Type | R-22, R-410A |
| Thermostatic Charge | CP100, GA, CP180, ZP180,, N |
| Evaporator Temperature | 40 °F, 5 °C |
| Liquid Temperature | 100 °F, 37.8 °C |
| Pressure Drop | 60 psi, 100 psi, 6 bar, 11 bar |
| Nominal Capacity | 1 to 6 ton |
| Inlet Connection Size | Chatleff, 3/8 to 1/2 inch ODF, 3/8 to 1/2 inch SAE |
| Outlet Connection Size | Chatleff, 3/8 to 5/8 inch (ODF), 1/2 inch (SAE) |
| Operating Pressure Max. | 31 bar, 48.3 bar, 450 psi, 700 psi |
| Equalizer Connection Type | 1/4 inch (ODF), 1/4 inch (SAE) Flare, 1/8 x 24 inch with 1/4" SAE Flare, Externally Equalized |
| Capillary Tube Length | 0.762 m, 1.524 m, 30 inch, 60 inch |
| Strainer Type | 100 Mesh Removable |
| Material | Brass |
| Stock Key | CON003 |
| Condition | New |
| SKU | 1103430 |
| Weight | 0,49 |
