Peter VB 400-60 APC Electronic DC Brake

Manufacturer: Peter
Type: Electronic DC brake
Model: VB 400-60 APC
Art. No.: 29731.40060

Application:
-ventilators and fans
-stirrers
-centrifuges
-saws
-conveyors
-wood working machines
-grinding machines
-drives with high load
Input voltage: 380/415 V AC ±10% /Single-phase
Frequency: 50/60 Hz
Output voltage: 0 … 220 V DC
Output current: 60 A
Output power: 15 Kw
Contact rating of output relays: 3A/30VDC
Delay time for reduction of residual: self-optimizing (200 … 3100ms)
Max. cross-sectional area: 16mm²
Ambient temperature: 0 … 45°C
Degree of protection: IP20
Dimensions: 110 x 140 x 242 mm
