Schneider ZB4 BZ104 Single Contact Block With Body Fixing Collar
Bloque de contacto simple con collar de fijación al cuerpo. El bloque de contacto Schneider Electric ZB4 BZ104 cuenta con 2 contactos NC, un collarín de fijación ZAMAK duradero y operación de ruptura lenta para aplicaciones de control industrial.
Schneider Electric ZB4 BZ104 Single Contact Block with Body Fixing Collar
The Schneider Electric ZB4 BZ104 is a complete body/contact assembly designed for reliable switching in industrial control systems. As part of the Harmony XB4 series, this contact block features a durable ZAMAK fixing collar, slow-break operation, and a high-rated insulation voltage, making it ideal for demanding applications.
Manufacturer: Schneider Electric
Type: Single Contact Block with Body Fixing Collar
Model: ZB4 BZ104
Part No.: 088940
Product or Component Type: Complete Body/Contact Assembly
Compatible With: Harmony XB4
Rated Operational Current:
3 A at 240 V, AC-15
6 A at 120 V, AC-15
0.1 A at 600 V, DC-13
0.27 A at 250 V, DC-13
0.55 A at 125 V, DC-13
1.2 A at 600 V, AC-15
| Rated Insulation Voltage | 600 V |
| Contacts Type and Composition | 2 NC |
| Rated Impulse Withstand Voltage | 6 kV |
| Fixing Collar Material | ZAMAK |
| Contact Operation | Slow-Break |
| Ambient Air Temperature for Operation | -40 to 70°C |
| Dimensions | 30 x 47 x 37 mm |
