Siemens 3RV2311-1EC10 Circuit Breaker
Nuevo
En stock1 unidadListo para enviar
Circuit Breaker SIEMENS 3RV2311-1EC10 SIRIUS circuit breaker with 4 A operational current, 690 V AC rating and 100 kA short-circuit breaking capacity.
Inventario Masivo
Envío global
Soporte experto
Calidad Garantizada
| Brand Name | SIRIUS |
| Designation | 3RV2 |
| Size | S00 |
| Operating Voltage | 690 V AC |
| Operational Current | 4 A |
| Frequency | 50 … 60 Hz |
| Power Loss | 7.25 / 2.4 W |
| Power AC-3 (400V) | 1.5 kW |
| Power (460/480V) | 2 HP |
| Insulation Voltage | 690 V AC |
| Rated Impulse Voltage Uimp | 6 kV |
| Rated Service Short-Circuit Breaking Capacity (Ics) | 100 kA |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu) | 100 kA |
| Protection Class | IP20 |
| Operation Temperature | -20 … 60 °C |
| Dimensions | 97 x 45 x 97 mm |
| Stock Key | CON003 |
| Condition | New |
| SKU | 1103916 |
| Weight | 0,34 |
