Telemecanique GVAN11 Auxiliary Contact Block
Nuevo
En stock20 unidadesListo para enviar
Auxiliary Contact Block
The Telemecanique Schneider GVAN11 is a compact NO+NC auxiliary contact block for TeSys devices, rated at 690 V with screw clamp terminals for secure panel installation.0660accessoryAuxiliaryBlockComponentContactControlElectricGVAN11motorNCNOPanelSchneiderStarterTelemecaniqueTeSysVDE
Usado
En stock
Este producto también está disponible usado
Ver versión usada →
Inventario Masivo
Envío global
Soporte experto
Calidad Garantizada
Telemecanique Schneider GVAN11 Auxiliary Contact Block
The Telemecanique Schneider GVAN11 Auxiliary Contact Block is a reliable add-on module designed for expanding signaling and control functions on TeSys motor protection devices. With a robust 690 V rating and a NO+NC contact configuration, it provides dependable performance in industrial control panels, automation systems, and motor starter assemblies. Engineered for long service life, stable connections, and easy installation.
Manufacturer: Telemecanique Schneider
Type: Auxiliary Contact Block
Model: GVAN11
Part No.: 034348
Range: TeSys
Series: GVAN
| Rated Operational Voltage (Ue) | 690 V |
| Rated Insulation Voltage (Ui) | 690 V |
| Conventional Free Air Thermal Current (Ith) | 6 A |
| Rated Operational Power | 720 VA (240 VAC) |
| Pole Contact Composition | 1 Normally Open (NO) + 1 Normally Closed (NC) |
| Connections / Terminals | Screw Clamp Terminals |
| Dimensions | 89 × 9.3 × 66 mm |
| Standard Compliance | VDE 0660 |
