THK HSR45CA1SS Linear Guideway Block
Nuevo
En stock1 unidadListo para enviar
Bloque de guía lineal THK HSR45CA1SS es un componente de precisión de alta resistencia con diseño de tipo brida, alta capacidad de carga y un sistema de sellado avanzado para un movimiento lineal óptimo.
AutomationBlockCNCFlangeGuideGuidewayHeavy-DutyHighHSR45CA1SSIndustrialLinearload-bearingMotionPrecisionSystemThkType
Inventario Masivo
Envío global
Soporte experto
Calidad Garantizada
THK HSR45CA1SS Linear Guideway Block
The THK HSR45CA1SS Linear Guideway Block is a high-precision, heavy-duty guideway component designed for smooth linear motion in industrial applications. With its robust flange-type structure, advanced sealing system, and high load-bearing capacity, this block ensures superior performance in demanding environments.
Manufacturer: THK
Type: Linear Guideway Block
Model: HSR45CA1SS
Basic Load Ratings:
| Size | 45 |
| Length | 139 mm |
| Width | 120 mm |
| Height | 60 mm |
| Height of Block | 50 mm |
| Block Type | Flange |
| Dynamic Load Rating | 82.2 kN |
| Static Load Rating | 101 kN |
| Mounting Hole | M12 |
| Seal | 1SS, with End Seal, Side Seal, and Inner Seal |
